Intellian MIM-2 Dish Wally Multi-satellite Interface Multi-switch (MIM) Adapter (AC110V)

Automatic Satellite Switching

The MIM-2 communicates with the Intellian antenna system and allows the antenna to switch automatically to the satellite carrying the selected DISH channel. Viewers can change channels with the Wally remote without manually reconfiguring the antenna control unit.

Built for DISH Wally Receivers

This MIM-2 version is designed specifically for DISH Network Wally receivers. It uses a different communication protocol from the earlier MIM and is not backward-compatible with DISH ViP211 or ViP711 receivers.

Multi-Receiver Support

Four receiver ports allow the module to serve as many as four Wally receivers. One connected receiver is selected as the master, and its channel selection determines which satellite the antenna tracks. Additional MIM units may be used when an installation requires more receiver connections.

Compatible Marine TV Systems

The MIM-2 is used with compatible Intellian i-Series, s-Series, and t-Series marine satellite TV antennas configured for DISH Network service in the United States. Compatibility should be confirmed against the antenna model, control unit, and receiver configuration before installation.

Below-Deck Installation

The module is intended for installation below deck in a dry, cool, ventilated location that remains accessible for setup and service. This configuration includes a 110V AC adapter to power the module from an onboard AC supply.
