Blue Sky Skylink Maruwa Iridium Dielectric-Loaded Decafilar-Helix Antenna

The Blue Sky SkyLink Maruwa MHL-1621C is a compact passive antenna designed for Iridium satellite communications. Its dielectric-loaded decafilar-helix design provides a broad reception pattern, helping compatible equipment maintain satellite visibility when the antenna is not aimed directly overhead. It is suited to SkyLink installations, Iridium messaging terminals, asset tracking systems, logistics equipment, emergency communications, and remote monitoring applications.

The antenna operates at 1621 MHz and connects through an SMA male interface. Its balanced design helps reject common-mode noise, while integrated filtering reduces interference from cellular and ISM frequency bands. The compact 57 mm body is useful where installation space is limited.

Satellite Phone Store can help confirm compatibility with Blue Sky SkyLink terminals, antenna cables, adapters, and installation requirements before deployment.

## Long Description

### Broad Iridium Reception

The MHL-1621C uses a dielectric-loaded decafilar-helix design with a beamwidth greater than 135 degrees. This broad radiation pattern supports communication with Iridium satellites across a wide portion of the sky and reduces the need for precise antenna alignment. It is intended for satellite phones, messaging terminals, tracking systems, research equipment, and emergency communication devices.

### Interference Management

The antenna incorporates filtering that attenuates signals from common cellular and ISM frequency bands by as much as 30 dB. Its balanced construction also helps reject noise introduced through the host equipment’s ground plane, supporting more consistent RF performance in installations containing other wireless or electronic systems.

### Compact Installation

Measuring 57 mm in height and 23 mm in diameter, the antenna provides an Iridium-compatible solution without requiring a large mounting area. It uses an SMA male connection and is designed to be installed with a 10 mm separation between the antenna side and the host PCB ground plane. Proper placement and clearance should be maintained to achieve the specified antenna performance.

### Remote and Operational Applications

The MHL-1621C is suitable for fixed or integrated Iridium communication systems used in logistics, asset tracking, emergency location, disaster response, research buoys, and other remote operations. Blue Sky Network documentation identifies it as a passive antenna used with SkyLink equipment, operating at 1621 MHz with right-hand circular polarization and 50-ohm impedance.
