Thuraya IP Voyager Tracking Antenna (HN222)
Description
Automatic Satellite Tracking
The HN222 continuously tracks the Thuraya satellite while the vehicle is in motion, allowing users to maintain broadband connectivity without manually pointing the antenna. This makes it suitable for applications where communications must remain available while traveling through remote or disaster-affected areas.
Built for Vehicle Installations
Designed specifically for Communications-on-the-Move (COTM), the antenna features magnetic mounting feet that allow installation in minutes without permanent vehicle modifications. Its compact, low-profile design minimizes wind resistance while remaining securely mounted during normal vehicle operation.
Rugged Design for Field Operations
The antenna is built for demanding outdoor environments and carries an IP56 ingress protection rating against dust and water. It is also designed to withstand vibration encountered during vehicle operation, making it suitable for emergency response, defense, border patrol, and utility applications.
Designed for Thuraya IP Voyager
The HN222 is engineered specifically for use with the Thuraya IP Voyager broadband terminal. It connects to the Below Deck Unit using a single RF cable that carries both power and communications, simplifying installation while maintaining reliable satellite connectivity.
Features
- Easy Installation
- Automatic satellite tracking
- IP56 weather protection
- Magnetic vehicle mounting
- Communications-on-the-Move
- Lightweight design
- Vehicle-ready installation
- Rugged construction
- Thuraya IP Voyager compatible
Package
Thuraya IP Voyager Tracking Antenna (HN222) Includes:
- Thuraya IP Voyager Tracking Antenna (HN222)
- Magnetic mounting feet
- RF cable (configuration dependent)
Technical Specifications
Power
- Powered directly by the Thuraya IP Voyager Below Deck Unit
- Single RF cable provides power and communications
Dimensions
- Diameter: 25.2 cm / 9.92 in
- Height: 11.9 cm / 4.69 in
Weight
- 2.0 kg (4.4 lb)
Durability
- IP56 ingress protection
- Designed for vehicle installations
- MIL-STD 810B vibration resistance
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +80°C
Additional
- Manufacturer: Thuraya
- Model: HN222
- Product type: Vehicular tracking antenna
- Designed for Thuraya IP Voyager
- Communications-on-the-Move (COTM) antenna
Data Network
- Compatible with Thuraya satellite broadband network
- Supports Standard IP up to 444 kbps
- Supports Streaming IP up to 384 kbps
Usage Control Features
- Automatic satellite tracking
- Communications-on-the-Move operation
- Magnetic quick installation
- Continuous tracking while driving
Interfaces
- RF connection to Thuraya IP Voyager Below Deck Unit
- Compatible with Thuraya IP Voyager system
